Santa Cruz Amilpas
Region: Central Valleys
Church construction date: late 18th - early 19th century
Organ construction date: 1884
Organ builder: Pedro Nibra (Oaxaca)
Last played: 1931
Organ classification: 8´ stationary organ
Tonal base: 8´ principal
Pitch: a=415 Hz, equal temperament
Case measurements: height 3.91 m, width upper and lower case 1.98 m, width lower case with hips 2.90 m, depth 1.11 m
Keyboard: it had 56 notes C - g''', LH chromatic, registers divided c'/c#'
Bellows: missing, but it had a reservoir bellows on the right side of the organ
Similar organs: Jalatlaco (built by Nibra 1866), Tehuantepec (1864)
The organ of Santa Cruz Amilpas is the last Oaxaca organ built in traditional style. The other organs in the state from the 1880s were built by Puebla organ builders, and the Amilpas organ incorporates a few of their innovations. The organ is terribly deteriorated, even though it is "young," because after the 1931 earthquake, the roof of the church cracked open and the organ was left unprotected for 30 years before the roof was reconstructed. So it was played for only 47 years. The organ was recently moved toward the railing of the choir loft in anticipation of repairs to the dome and was unfortunately damaged even more. The photo is a composite, since the current position of the organ makes a portrait photo impossible.
SPECIFICATIONS
Left hand: 25 notes C - c'
1. Clarín (bajoncillo) 4´
2. Flautado mayor 8´
3. Octava 1° 4´
4. Quincena 2´
5. Tapadillo 4´
6. Octava 2° 4´
7. Trompeta real 8´
Right hand: 31 notes c#’- g’’’
1. Clarín 8´
2. Flautado mayor 8´
3. Octava 1° 4´
4. Quincena 1° 2´
5. Tapadillo 4´
6. Octava 2° 4´
7. Quincena 2° 2´
